1.3 Front Panel Features

The server system provides the following features on the system's front panel:
Eight 2.5-inch Hot-swap SATA/SAS Hard Drive Bays—four for each installed server
node.
Dual independent front control panels—one for each installed server node.
Features found on each front control panel include: System Power and System Reset
buttons, LED indicators, and one 2.0 USB port.
2
Per Server Node:
1 x External DB-9 Serial Port
2 x RJ-45 LAN ports (stacked)
1 x RJ-45 Management LAN port
3 x USB 2.0 ports (Front x 1, Rear x 2)
1 x Internal A-type USB Port
1 x VGA port
Eight 4-pin managed system fan. (Four fans per server node)
2 x PCI Express* X16 GEN2 slots supporting low-profile half height add-in cards
(one per server node)
On-board ASPEED* AST2050 with integrated Video Controller
Integrated 2D Video Controller
8 MB Video Memory
8 x 2.5-inch hot-swap SATA Hard Drive Bays (Four drive bays per server node)
Embedded support for the following RAID solutions:
®
Intel Matrix Storage Manager with Software RAID levels 0/1/5/10 (Windows*
Only)
LSI* Software RAID supporting RAID levels 0/1/10 (Windows and Linux)
Dual 770-W cold swap Power Supply modules. (non-redundant)
4 x 10/100/1000 Ethernet ports provided by Intel
Acceleration Technology (Two LAN ports per server node)
On-board ASPEED AST2050 with integrated Baseboard Management
Controller
2 x BMC Management Modules with IPMI 2.0 support (One per server node)
2 x 10/100 Management LAN port (One per server node)
686 mm x 444 mm x 43.4 mm
Description
®
82574L PHYs with Intel
®
Intel Server System SR1670HV Service Guide
®
I/O
