1.4 Rear Panel Features

You can find the following features on the server system back panel:
Dual tool-less cold-swap, non-redundant power supplies—one for each installed server
node.
Add-in card slot covers for each installed server node.
External I/O ports for each installed server node.

1.5 Internal Features

The following figure shows the internal features of the server system.
®
Intel Server System SR1670HV Service Guide
System ID LED
System ID Button

Figure 1. Server System Features

Figure 2. System Features – Back Panel
Product Introduction
3
