BIOS Updates and Configuration
6.3.3.6 System Information Sub-Menu
This menu gives you an overview of the general system specifications. The BIOS
automatically detects the items in this menu.
OS SETUP UTILITY
6.3.3.6.1
Displays the auto-detected BIOS information.
6.3.3.6.2
Displays the auto-detected processor information.
6.3.3.6.3
Displays the total system memory detected.
6.3.3.6.4
Displays the MAC Address assigned to on-board LAN Ports 1 and 2
6.3.3.6.5
Sub-Menu option that provides information for each detected DIMM attached to
Processors 1 and 2. Information provided for each installed DIMM includes: Slot ID, size,
rank, speed, and current operating temperature.
56

Figure 88. System Information Menu

AMIBIOS
Processor
System Memory
LAN# Address
System Memory Information

Figure 89. System Memory Information Menu

®
Intel Server System SR1670HV Service Guide
