Installing and Removing the RAID Activation Key and
the RAID Mini-DIMM (Active Systems Only)

Installing the RAID Activation Key and the RAID Mini-DIMM

To install the RAID activation key and RAID Mini-DIMM, follow these steps:
1. Remove the PCI riser assembly. For instructions, see
Assembly" on page
2. Remove the processor air duct. For instructions, see
Duct" on page
3. Remove the large air baffle. For instructions, see
on page
4. Install the RAID activation key by pushing straight down into the RAID key socket
(see letter "A" in
5. Install the RAID mini-DIMM as follows:
a. Open both socket levers (see letter "B" in
b. Insert the DIMM into the socket (see letter "C" in
c. Push firmly on the DIMM until it snaps into place and both levers close.
6. Install the large air baffle. For instructions, see
page
®
Intel Server System SR2600UR/SR2625UR Service Guide
50.
56.
70.
Figure
connector edge of the DIMM aligns correctly with the slot.
Open Levers
C
B

Figure 105. Installing the RAID Activation Key and the RAID Mini-DIMM

70.
105).
Figure
RAID Mini DIMM
Socket
B
"Installing the Large Air Baffle" on
"Removing the PCI Riser
"Removing the Processor Air
"Removing the Large Air Baffle"
105)
Figure 105) making sure the
RAID
Key
®
Intel RAID
Activation
Key Socket
A
AF002976
