Draytek Vigor2136 Series User Manual page 96

Garbage Timer
Connected
Static
BGP
OSPF
Enabled
Update Timer
Timeout Timer
Garbage Timer
Connected
Static
BGP
OSPF
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
expiration set in this field.
The information will be kept in the routing table temporarily. At the
same time, the neighbors will be notified that the route has been
dropped.
The route will be removed from the routing table upon the expiration
set in Garbage Timer.
Switch the toggle to enable/disable the function.
All Networks – Apply the RIP profile to all the LAN interfaces.
Exclude NAT Networks - Apply the RIP profile to all the LAN
interfaces except for NAT network.
Switch the toggle to enable (apply the static route to the RIP profile) or
disable the function.
Switch the toggle to enable (allow dynamically route traffic based on
information learned from the BGP protocol) or disable the function.
Switch the toggle to enable (allow dynamically route traffic based on
information learned from the OSPF protocol) or disable the function.
RIPng
Switch the toggle to enable/disable the function of Routing
Information Protocol next generation (RIPng).
Enter a value as the update timer.
When the time is up, the Vigor router will send a message containing
the complete routing table to all neighboring routers for exchanging
the routing information.
The routing information will be valid (but not removed) till the time
expiration set in this field.
The information will be kept in the routing table temporarily. At the
same time, the neighbors will be notified that the route has been
dropped.
The route will be removed from the routing table upon the expiration
set in Garbage Timer.
Switch the toggle to enable (apply the RIPng settings to all the LAN
interfaces) or disable the function.
Switch the toggle to enable (apply the static route to the RIP profile) or
disable the function.
Switch the toggle to enable (allow dynamically route traffic based on
information learned from the BGP protocol) or disable the function.
Switch the toggle to enable (allow dynamically route traffic based on
information learned from the OSPF protocol) or disable the function.
Discard current settings.
Save the current settings.
86
