IV-2-1-2 Traceroute
The user can perform the traceroute job for specified IP (host) to diagnose if the data transmission
via the Vigor system is well or not.
Available settings are explained as follows:
Item
IP Version
Trace Through
Protocol
Host/IP Address
Trace Count
Max Hop
Clear
Run
Description
Select the IP version for entering correct IP address.
Trace through specific interface. Only Auto is available for selection.
Select ICMP or UDP protocol.
Enter the host / IP address that you want to traceroute.
Select the max hops for traceroute, select none for unlimited.
Set the maximum number of hops to search for the target.
Remove the settings and return to the factory settings.
Perform the job.
