Available settings are explained as follows:
Item
Reset
Refresh
Enabled
Band
2.4GHz SSID / 5GHz
SSID
Method 1: WPS Button
Method 2: Using PIN
Code
Connection Status
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
Description
Click to reset WPS with the default value.
Click to refresh current page.
Switch the toggle to enable/disable the function.
Select the band (2.4GHz/5GHz) for this function.
Displays the SSID used for 2.4GHz/5GHz.
Enable WPS – Switch the toggle to enable/disable the function.
Start PBC –Click it to invoke the Push-Button style WPS setup
procedure. The router will wait for about 2 minutes for WPS
connection requests from wireless clients. The ACT LED and WLAN
LED on the router will blink fast simultaneously when WPS is in
progress and will return to normal condition after two minutes.
Enter a PIN code, and click the Connect button.
Generate PIN code from – At present, only Client is available.
Client PIN Code – Enter a PIN code.
Connect – Click it to make a connection. The ACT LED and WLAN LED
on the router will blink fast simultaneously when WPS is in progress,
for up to 2 minutes or until a successful WPS connection from a
wireless client has been established.
Displays the connection status after clicking Connect or Start PBC.
Discard current settings.
Save the current settings.
