II-1-5-2 Radio Settings
This page lets you configure the most basic settings of your wireless network, including mode,
WLAN channels and channel bandwidth.
Available settings are explained as follows:
Item
Advanced
Mode:ON/OFF
Enabled
Mode
Transmit Power
Channel
Channel Bandwidth
Description
Click to show or hide the advanced settings for the Radio settings.
2.4GHz Radio
Switch the toggle to enable/disable the RADIO settings.
Select the 802.11 mode allowed on the band.
On the 2.4GHz band on
mode options are available:
• 11b Only
• 11g Only
• 11n Only (2.4 GHz)
• Mixed (11b+11g)
• Mixed (11g+11n)
• Mixed (11b+11g+11n)
• Mixed (11b+11g+11n+11ax)
Sets the power percentage of the access point's transmission signal.
The greater the TX Power value, the higher intensity of the signal will
be.
Allows you to specify a particular wireless channel to use, or let the
system determine the optimal channel by selecting "Auto Select". The
list of available channels varies depending on the locale for which the
router is intended.
20 MHz –Vigor Router will utilize 20 MHz channels for data
transmission and reception between the router and wireless stations.
40 MHz – Vigor Router will utilize 40 MHz for data transmission and
67
ax models (2136ax), the following wireless
