Draytek Vigor2136 Series User Manual page 91

Secondary Path
Last Resort Path
Primary Path LAN - It is available when the LAN is selected.
+Add – Click +Add to create a new VPN path. Use the drop-down list to
select a VPN profile.
Disabled – Disable the function settings for the secondary path.
Secondary Path WAN – It is available when the WAN/Virtual WAN is
set for Secondary Path.
+Add – Click +Add to create the secondary path by specifying WAN
settings.
Secondary Path VPN - It is available when the VPN is set for
Secondary Path.
+Add – Click +Add to create a new VPN path.
Secondary Path LAN - It is available when the LAN is set for
Secondary Path.
+Add – Click +Add to create a new LAN path.
The last resort path (setting) will be adopted instead once the Primary
Path or the Secondary Path could not be used for directing the traffic.
Disabled –Disable the function settings for the Last Resort Path.
Any packet matching with the rule (source/destination/protocol)
specified in Criteria above, will be forwarded to the interface defined
on Last Resort Path.
Default WAN – The default WAN interface will be used for the last
resort path.
Gateway – Select Default or Customize.

Gateway IP Address – Enter the IP address of the gateway if

Customize is selected.
Force NAT/Routing – Determine which mechanism (Force

NAT/Routing) that the router will use to forward the packet to
WAN.
WAN/Virtual WAN – Specify a WAN interface or a virtual WAN
interface for the last resort path.
Last Resort Path WAN – Click +Add. Then select a WAN interface,

the IP address (WAN), the gateway IP address(LAN) and the packet
forwarding mechanism.
81
