Available settings are explained as follows:
Item
Name
Resource Type
Resource IP / MAC
Resource Port
Allow ICMP
Description
Enter a name for identification.
Select IP or MAC as the resource type.
Enter the IP address or MAC address according to the resource type
selected for this profile.
Select the resource port type.
All TCP/UDP ports - Transmission Control Protocol and User
Datagram Protocol
All TCP ports - Transmission Control Protocol
All UDP ports - User Datagram Protocol
Specify ports – Select this port type and set the port number for
TCP/UDP, TCP, or UDP respectively.
Service Type Object – Up to 12 service-type object profiles can
be set in this field.
Click +Add to display the available service type list to the right side.
Select the one(s) you want.
It's for diagnostic and control purposes, to send error messages about
IP operations, messages about requested services, or messages about
the reachability of a host or router.
195
