Item
Name
Enabled
Schedule
Direction
Specify Interface
Source
Destination
Description
Enter a name to identify the rule.
Switch the toggle to enable/disable this profile.
Always On – This rule is enabled and active for always.
Scheduled On - Select Schedule indexes to allow the rule to be
enabled at specific times. You may choose up to 4 out of the 15
schedules in Configurations>>Objects>>Schedule. The rule is always
enabled when no indexes have been selected.
Clear Session when Schedule is On - Select this option to clear

existing sessions when the rule is changes is enabled by a
schedule profile. All connections will be reset.
Specify the direction of traffic flow to which this filter rule applies.
LAN to WAN

WAN to LAN

LAN/VPN to LAN/VPN

Switch the toggle to enable/disable the function.
If enabled, specify the interfaces for the traffic flow.
Source Interface – Select the LAN/VPN interface(s).
Destination Interface – Select the WAN interface(s).
Criteria
Configure the source IP addresses.
To set the IP address manually, please choose Any / IPv4 Address /
IPv4 Subnet / IPv6 Address / IPv6 Subnet / IP Object / IP Group /
MAC Object / MAC Group as the source and enter required
information.
Any – All IP addresses
IPv4 Address–Enter the IP address.
Source IPv4 Address – Click +Add to enter the IP address.

IPv4 Subnet–Enter the IP Address and the Subnet Mask.
Source IPv4 Subnet Address - Click +Add to enter the IPv4 address

with a subnet mask.
IPv6 Address–Enter the IPv6 address.
Source IPv6 Address – Click +Add to enter the IPv6 address.

IPv6 Subnet–Enter the IPv6 Address and the prefix length.
Source IPv6 Subnet Address - Click +Add to enter the IPv6 address

with a subnet mask.
IP Object–Allows selection of predefined IP Objects.
Source IP Object – Click +Add to select an IP object.

IP Group –Allows selection of predefined IP Groups.
Source IP Group - Click +Add to select an IP group.

MAC Object–Allows selection of predefined MAC Objects.
Source MAC Object – Click +Add to select an MAC object.

MAC Group –Allows selection of predefined MAC Groups.
Source MAC Group - Click +Add to select an MAC group.
Configure the destination IP addresses.
To set the IP address manually, please choose Any / IPv4 Address /
