For Physical Type with Ethernet
Ethernet WAN and Port 1 can be configured as the WAN interfaces. WAN connections for these two
ports can be configured separately.
Click the Edit link for WAN1 or WAN2 (LAN port 1) to open the following page.
Available settings are explained as follows:
Item
Advanced
Mode:ON/OFF
Index
Profile Name
Enabled
Physical Type
Bind to Physical
Interface
IP Version
Description
Click to show or hide the advanced settings (IP Alias and WAN MAC
Address) for the WAN interface.
Displays current WAN interface.
Displays the name of the profile.
Switch the toggle to enable or disable the function.
General Setup
Displays the physical type used by this interface.
Select a physical interface (Ethernet). If LAN port 1 has been set as
WAN port, it will be shown as Port 1 (Enabled) available for chosen as
the WAN interface.
Set the protocol (IPv4 or IPv6 or both) that this WAN interface used.
