Draytek Vigor2136 Series User Manual page 78

Current Channel
Current Extension
Channel
Update Channel
Updated Channel
Result
Enabled
Mode
Transmit Power
Channel
Channel Bandwidth
Current Channel
Update Channel
Updated Channel
Result
reception between the router and wireless stations.
Auto 20/40 MHz – Vigor Router will utilize either 20 MHz or 40 MHz
for data transmission and reception depending on the number of AP
nearby the router. 20MHz will be used when there are more than 10
wireless APs; otherwise 40MHz will be used. Selecting this setting
ensures the best performance for data transit on networks with both
20 MHz and 40 MHz clients.
Displays current used channel number.
Displays current used extension channel number.
Scan and Update - Click to select the best channel again when Auto
Select is selected as the Channel setting.
Displays the best channel after pressing the Scan and Update button.
5GHz Radio
Switch the toggle to enable/disable the RADIO settings.
Select the 802.11 mode allowed on the band.
On the 5GHz band on ax models (2136ax), the following options are
available:
• 11a Only
• 11n Only (5 GHz)
• Mixed (11a+11n)
• Mixed (11a+11n+11ac)
• Mixed (11a+11n+11ac+11ax)
Sets the power percentage of the access point's transmission signal.
The greater the TX Power value, the higher intensity of the signal will
be.
Allows you to specify a particular wireless channel to use, or let the
system determine the optimal channel by selecting "Auto Select". The
list of available channels varies depending on the local for which the
router is intended.
20 MHz –Vigor Router will utilize 20 MHz for data transmission and
reception between the router and wireless stations.
40 MHz – Vigor Router will utilize 40 MHz for data transmission and
reception between the router and wireless stations.
80 MHz –Vigor Router will utilize 80 MHz for data transmission and
reception between the router and wireless stations.
160 MHz – Vigor Router will utilize 160 MHz for data transmission and
reception between the router and wireless stations.
Displays current used channel number.
Scan and Update - Click to select the best channel again when Auto
Select is selected as the Channel setting.
Displays the best channel after pressing the Scan and Update button.
68
