For Physical Type with Wireless 2.4GHz
When Wireless 2.4G is selected as Physical Type, WAN interface uses wireless station mode to
access Internet. The Router acts as a 2.4GHz wireless station and connects to the specific Wireless
AP.
Click the Edit link for WAN3 or WAN4 to open the following page.
Available settings are explained as follows:
Item
Advanced
Mode:ON/OFF
Index
Profile Name
Enabled
Physical Type
Bind to Physical
Interface
Peer SSID
Channel
Security Mode
Description
Click to show or hide the advanced settings (WAN MAC Address) for
the WAN interface.
Displays current WAN interface.
Displays the name of the profile.
Switch the toggle to enable or disable the function.
General Setup
Displays the physical type used by this interface.
At present, only Wireless 2.4GHz is available for WAN3 and Wireless
5GHz for WAN4.
Enter the identification of the wireless device.
Select the channel of frequency of the device.
There are several modes provided for you to choose from. Each mode
will bring up different parameters (e.g., Pass Phrase) for you to
