Available settings are explained as follows:
Item
Enabled
Quota
When quota exceed
Time Cycle
When Monthly is
selected as the Time
Cycle
When Custom is
selected as the Time
Cycle
SMS Alert
Email Alert
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
Description
Switch the toggle to enable or disable the profile.
When enabled, the WAN Budget is enabled for this WAN.
Enter the data traffic quota allowed for such WAN interface. There are
two unit (MB and GB) offered for you to specify.
Shutdown WAN interface - All the outgoing traffic through such
WAN interface will be halted when the traffic has exceeded the budget
limit.
Monthly – Some ISP might apply for the network limitation based on
the traffic limit per month. This setting is to offer a mechanism of
resetting the traffic record every month.
Custom - This setting allows the user to define the billing cycle
according to his request. The WAN budget will be reset with an
interval of billing cycle.
Data quota resets on day - You can determine the starting day in
one month.
Monthly is default. If long period or a short period is required, use
Custom. The period of cycle duration is between 1 day and 30 days.
You can determine the cycle duration by specifying the days and the
hours. In addition, you can specify which day of today is in a cycle.
Cycle duration (Days) – Specify the days (1~31) to reset the traffic
record.
Cycle duration (Hours) – Specify the hours (0~23) to reset the traffic
record.
Start Date – Specify the day in the cycle as the starting point which
Vigor router will reset the traffic record.
Start Time (Hr:Min.) - Specify the time for data quota rest in the cycle
as the starting point which Vigor router will reset the traffic record.
Switch the toggle to enable or disable the function.
Send Alert SMS to – The system will send out SMS message to the
user specified here when the quota is running out (less than 10%).
Switch the toggle to enable or disable the function.
Send Alert Email to – The system will send out a warning message to
the user specified here when the quota is running out (less than 10%).
Discard current settings and return to previous page.
Save the current settings and exit the page.
