I-2 Hardware Installation
This section will guide you to install the Vigor2136 through a hardware connection and configure
the device's settings through the web browser.
I-2-1 Network Connection
1.
Connect the cable Modem/DSL Modem/Media Converter to any WAN port of router with
Ethernet cable (RJ-45).
2.
Connect one end of an Ethernet cable (RJ-45) to one of the LAN ports of the router and the
other end of the cable (RJ-45) into the Ethernet port on your computer.
3.
Connect one end of the power cord to the power port of this device. Connect the other end to
the wall outlet of electricity.
4.
For ac series, connect detachable antennas to the router.
5.
Power on the router. Check the ACT and WAN, LAN LEDs to assure network connection.
(For the detailed information of LED status, please refer to section 2. Panel Explanation)
5
