- Page 1 Vigor2136 Series Gigabit Broadband Router Quick Start Guide Version: Firmware Version: V5.3.0 (For future update, please visit DrayTek web site) Date: September 6, 2024...
- Page 2 Intellectual Property Rights (IPR) Information © All rights reserved. This publication contains information that is protected Copyrights by copyright. No part may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright holders. The following trademarks are used in this document: Trademarks Microsoft is a registered trademark of Microsoft Corp.
-
Page 3: Declaration Of Conformity
Declaration of Conformity Hereby, DrayTek Corporation declares that the equipment type Vigor2136 series is in compliance with Radio Equipment Directive 2014/53/EU, Low Voltage Directive 2014/35/EU and RoHS 2011/65/EU. The full text of the EU Declaration of Conformity is available at the following internet address: https://fw.draytek.com.tw/Vigor2136/Document/CE/... -
Page 4: Regulatory Information
Regulatory Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 5 89.3% efficiency Efficiency at 73.6% 78.0% 81.3% 83.3% 83.7% 74.5% 80.5% 86.4% 85.4% 85.4% 84.7% 87.7% low load 10% No-load power 0.07W 0.07W 0.07W 0.07W 0.07W 0.07W 0.10W 0.07W 0.10W 0.10W 0.08W 0.10W consumption For more update, please visit www.draytek.com.
-
Page 6: Table Of Contents
1. Package Content................1 2. Panel Explanation ................2 2.1 Vigor2136ax / Vigor2136Fax ................2 2.2 Vigor2136Vax / Vigor2136FVax ................4 3. Hardware Installation ..............6 3.1 Network Connection ..................6 3.2 Wall-Mounted Installation................7 4. Software Configuration ..............8 5. Customer Service ................. 10... -
Page 7: Package Content
Take a look at the package content. If there is anything missed or damaged, please contact DrayTek or dealer immediately. Vigor2136 series Quick Start Guide RJ-45 Cat-5 Ethernet Cable Antenna (for ax only) The type of the power adapter depends on the country that the router will be installed. -
Page 8: Panel Explanation
Status Explanation Blinking The router is powered on and running normally. When both ACT and WLAN LEDs blink quickly, it Blinking means the WPS function is enabled and active. The system is waiting for a wireless station of (quickly) (Activity) connection. - Page 9 Interface Description Wireless LAN WLAN On - Press the button and release it within 2 seconds. When ON/OFF/WPS the wireless function is ready, the green LED will be on. WLAN Off - Press the button and release it within 2 seconds to turn off the WLAN function.
-
Page 10: Vigor2136Vax / Vigor2136Fvax
Status Explanation Blinking The router is powered on and running normally. When both ACT and WLAN LEDs blink quickly, it Blinking means the WPS function is enabled and active. The system is waiting for a wireless station of (quickly) (Activity) connection. - Page 11 Interface Description Wireless LAN WLAN On - Press the button and release it within 2 seconds. When ON/OFF/WPS the wireless function is ready, the green LED will be on. WLAN Off - Press the button and release it within 2 seconds to turn off the WLAN function.
-
Page 12: Hardware Installation
This section will guide you to install the router through hardware connection and configure the router’s settings through web browser. Before starting to configure the router, you have to connect your devices correctly. Here we take Vigor2136ax as an example. Connect the cable Modem/DSL Modem/Media Converter to any WAN port of router with Ethernet cable (RJ-45). -
Page 13: Wall-Mounted Installation
Vigor2136 series has keyhole type mounting slots on the underside. Drill two holes on the wall. The distance between the holes shall be 168mm. Fit screws into the wall using the appropriate type of wall plug. With the screws installed, the router can be slotted into place. -
Page 14: Software Configuration
By default, you can access the Internet if you finish the hardware installation. However, you might need to access the web user interface of the Vigor router for some reason; for this, follow the steps listed below. Make sure your PC connects to the router correctly. Open a web browser on your PC and type https://192.168.1.1. - Page 15 You MUST change the login password before accessing the web user interface. Please set a new password for network security. Now, the Main Screen will pop up. Note The home page will change slightly in accordance with the router you have.
-
Page 16: Customer Service
If the router cannot work correctly after trying many efforts, please contact your dealer/DrayTek for further help right away. For any questions, please feel free to send e-mail to support@draytek.com. Web registration is preferred. You can register your Vigor router via https://myvigor.draytek.com.
