Protocol
Service Type Object
Specify Source Port
Destination Port
Protocol Number
Fragment
IPv4 Subnet / IPv6 Address / IPv6 Subnet / IP Object / IP Group as
the destination and enter required information.
Any – All IP addresses
IPv4 Address–Enter one IPv4 address.
Destination IPv4 Address – Click +Add to enter the IP address.

IPv4 Subnet–Enter the IPv4 Address and the Subnet Mask.
Destination IPv4 Subnet Address - Click +Add to enter the IPv4

address with a subnet mask.
IPv6 Address–Enter the IPv6 address.
Destination IPv6 Address – Click +Add to enter the IPv6 address.

IPv6 Subnet–Enter the IPv6 Address and the prefix length.
Destination IPv6 Subnet Address - Click +Add to enter the IPv6

address with a subnet mask.
IP Object–Allows selection of predefined IP Objects.
Destination IP Object – Click +Add to select an IP object.

IP Group –Allows selection of predefined IP Groups.
Destination IP Group - Click +Add to select an IP group.

Specify the protocol(s) which this filter rule will apply to.
Any

Service Object

TCP/UDP

TCP

UDP

ICMP

ICMPv6

IGMP

Others

It is available when Service Object is set as the Protocol.
Click +Add to select the service type objects (up to 12) you want.
Switch the toggle to enable / disable the port settings.
Source Port – If enabled, please provide the starting and ending port
values.
It is available when TCP or UDP is set as the Protocol.
To define a port range, please provide the starting and ending port
values.
It is available when Others is set as the Protocol.
Enter a value as the protocol number.
Action to be taken for fragmented packets.
