Draytek Vigor2136 Series User Manual page 89

Available settings are explained as follows:
Item
Policy Name
Enabled
Schedule
Source / Destination
Source / Destination
IPv4 Address
Source / Destination
IPv4 Subnet Address
Description
Enter a name as the routing profile name.
Switch the toggle to enable/disable the profile.
Determine the valid time for the routing profile.
Always On – The routing profile will be valid all the time if it is
enabled.
Scheduled On – The routing profile will be valid based on the time
schedule specified here.
Criteria
Select the type of IP addresses to which this rule is to be applied.
Any - This policy applies to all source/destination IP addresses.

IPv4 Address - This policy applies to the specified range of source

IP addresses.
IPv4 Subnet - This policy applies to source IP addresses defined

by the specified network IP address and subnet mask.
IP Object - This policy applies to a preconfigured IP object.

IP Group - This policy applies to a preconfigured IP group.

It is available when Source / Destination is set as IPv4 Address.
+Add – Click to have new entries for setting IPv4 Address Start and
End.
IPv4 Address Start / End – Enter two IPv4 address(s), one for start
and one for end.
Delete – Click to remove current entries.
It is available when Source / Destination is set as IPv4 Subnet.
+Add – Click to have new entries for setting IPv4 subnet.
IPv4 Address – Enter an IP address.
Subnet Mask - Use the drop down list to choose a suitable mask for
79
