II-1-2 WAN
II-1-2-1 WAN Connections
This page is to configure the general settings for WAN connection.
Available settings are explained as follows:
Item
Name
Enabled
Mode
Physical Type
IPv4 Connection Type
IPv4 Address
IPv6 Connection Type
Link Local Address
Option
To configure the detailed settings (varied by physical type) for the selected WAN interface, click the
Edit link to the right side of the WAN interface.
Description
Displays the name of the interface.
Displays if the WAN interface is enabled or disabled.
Displays if the WAN interface is primary or failover interface.
Displays the physical type (e.g., Ethernet, Wireless 2.4GHz, Wireless
5GHz or USB) of the WAN interface.
Displays the IPv4 connection type (e.g, Static IP, DHCP and etc.) used
by the WAN interface.
Displays the IP address assigned by the DHCP server or the static IP
address specified manually.
Displays the IPv6 connection type used by the WAN interface.
Displays the IPv6 address for the IPv6 connection type – Static.
Edit - Click to modify the interface name and physical mode.
