Draytek Vigor2136 Series User Manual page 122

+Add
Protocol
Public Port Start
Public Port End
Private Port Start
Private Port End
Option
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
Single – Specify a destination LAN IP address that will receive the
forwarded traffic.
Range – Specify a range of destination LAN IP addresses that will
receive the forwarded traffic.
Port Forwarding
Click to set port numbers for the specified protocol (TCP, UDP, or
TCP/UDP) for a port forwarding profile.
The protocol to which this rule applies, TCP, UDP or TCP/UDP.
Specify which port can be redirected to the specified Private IP and
Port of the internal host. Enter the required number as the starting
port.
Enter the required number as the ending port.
The port on each LAN client to which the traffic will be directed to.
Enter the required number as the starting port.
Enter the required number as the ending port.
Click Delete to remove the selected entry.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
112
