Port Profile
This page configures the speed, duplex mode, and port profile for each GE port of the VigorSwitch.
Available settings are explained as follows:
Item
Port
Description
Port Enabled
Port Speed
Description
Display the number of the GE port.
If required, enter a brief description to explain the device connected
to VigorSwitch via the LAN port.
The port (e.g., GE2 in this case) which is used to connect VigorSwitch
and Vigor router will not be shutdown by Vigor router.
Other LAN ports of VigorSwitch allow to connect to any LAN device.
When it is checked, after clicking Apply, the network connection
between that device and VigorSwitch will be terminated.
Ethernet speed is set automatically by router system or manually set
to 10M/100M/1000M/2G bit/s.
Port speed capabilities:
Auto: Auto speed with all capabilities.

Auto(10M): Auto speed with 10M ability only.

Auto(100M): Auto speed with 100M ability only.

