Draytek Vigor2136 Series User Manual page 163

Key Type
Algorithm
Type
Country (C)
State (ST)
Location (L)
Organization (O)
Organization Unit (OU)
Common Name (CN)
Email (E)
Cancel
Apply
File Type
Cancel
and Certificate with a private key.
Method - Generate CSR
Displays the key type used by the certificate.
Displays the algorithm for generating the certificate.
Select the type of Subject Alternative Name and enter its value.
IP Address

Domain Name

Email

Enter the country name (code) in which your organization is located.
Enter the state or province where your organization is located.
Enter the city where you're your organization is located.
Enter the legal name of your organization.
Enter the department within your organization that you wish to be
associated with this certificate.
Enter the fully-qualified domain name / WAN IP that will be used to
reach your server.
Enter the email address of the entry.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
Method - Import Certificate & Keys
Vigor router allows you to generate a certificate request and submit it
the CA server, then import it as "Local Certificate". If you have already
gotten a certificate from a third party, you may import it directly. The
supported types are PKCS12 Certificate and Certificate with a private
key.
Certificate Only - Local certificate.
Upload Certificate - Click Choose a file to select a local

certificate file.
PKCS12 - Users can import the certificate whose extensions are
usually .pfx or .p12. And these certificates usually need passwords.
PKCS12 is a standard for storing private keys and certificates securely.
It is used in (among other things) Netscape and Microsoft Internet
Explorer with their import and export options.
Upload PKCS12 File - Click Choose a file to select a PKCS12

certificate file.
Password - Enter the password associated with the certificate

and key files.
Certificate & Keys - It is useful when users have separated
certificates and private keys. And the password is needed if the
private key is encrypted.
Upload File - Click Choose a file to select a local certificate file.

Upload Key - Click Choose a file to select a key file.

Password - Enter the password associated with the certificate

and key files.
Discard current settings and return to the previous page.
153
