QoS
This page is used to configure port settings for QoS. The configuration result for each port will be
displayed on the table listed on the lower side of this web page.
Available settings are explained as follows:
Item
Profile Name
Ingress Default CoS
Egress Remark CoS
Egress Remark
DSCP/IP Precedence
Enable Ingress Rate
Limit
Enable Egress Rate
Limit
Description
Enter a name for the Switch. The purpose of name is used for
identification.
It is useful when there are many VigorSwitch (same modes) devices
connecting to Vigor router.
Specify the default CoS priority value for those ingress frames without
given trust QoS tag (802.1q/DSCP/IP Precedence, depending on
configuration).
Switch the toggle to enable/disable the function.
Disabled - Select to disable this function.
DSCP - Egress traffic will be marked with DSCP value according to the
Queue to DSCP mapping table.
IP Precedence - Egress traffic will be marked with IP Precedence value
according to the Queue to IP Precedence mapping table.
This page is used to configure port settings for QoS. The configuration
result for each port will be displayed on the table listed on the lower
side of this web page.
Switch the toggle to enable/disable the function.
Ingress Rate Limit - Enter the rate value (16-1000000), unit:16 Kbps.
This page is used to configure port settings for QoS. The configuration
result for each port will be displayed on the table listed on the lower
side of this web page.
Switch the toggle to enable/disable the function.
Egress Rate Limit - Enter the rate value (16-1000000), unit:16 Kbps.
