Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
II-1-14-3 USB Device Status
This page allows monitoring of the status of USB devices (disk, modem, printer, and sensor)
connected to the Vigor router.
Available settings are explained as follows:
Item
Connection Status
Disk Capacity
Free Capacity
USB Disk Users
Connected
specified here.
File Access Rule – Check the items (Read, Write and Delete) for such
profile.
Directory Access Rule – Check the items (List, Create and Remove)
for such profile.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
Description
Shows whether a USB disk is connected or not. If there is no USB
device connected to the Vigor router, "No Disk Connected" will be
displayed.
Shows the total capacity of the USB storage disk.
Shows the free space on the USB storage disk. Click Refresh at any
time to get the most up-to-date free capacity.
Shows the clients that are connected to the SMB/FTP server.
Index – The profile index used by the client to establish the
connection.
Service – Shows whether the connection is using FTP or SMB.
IP Address – Shows the client's IP address.
Username – Shows the username used to establish the connection.
