Tagged VLAN
Options under the Advanced Mode
Forbidden VLAN
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
GVRP
This page allows the network administrator to configure registration mode (e.g., Normal, Fixed or
Forbidden) of GVRP (GARP VLAN Registration Protocol) for each GE port.
Such function can eliminate unnecessary network traffic and prevent any attempt to transmit
information to unregistered users.
Available settings are explained as follows:
Item
Profile Name
Enabled
Dynamic VLAN
Creation
Registration
Select all VLAN profiles or independent VLAN profiles to be tagged in
the VLAN.
The GE port set in a VLAN profile allows default VLAN packet to pass
through.
Select the VLAN profile as forbidden VLAN.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
Description
Enter a name for the Switch. The purpose of name is used for
identification.
It is useful when there are many VigorSwitch (same modes) devices
connecting to Vigor router.
Switch the toggle to enable / disable the GVRP port setting.
Switch the toggle to enable / disable the VLAN creation.
There are three modes to be specified.
Normal – Default setting. All packets can pass through the selected
246
