MTU
Mode
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
For Physical Type with Wireless 5GHz
When Wireless 5G is selected as Physical Type, WAN interface uses wireless station mode to access
Internet. The Router acts as a 5GHz wireless station and connects to the specific Wireless AP.
Available settings are explained as follows:
Item
Advanced
Mode:ON/OFF
Index
Profile Name
Enabled
Physical Type
Bind to Physical
Maximum Transmission Unit, the size of the largest packet, in bytes,
that can be transmitted to the WAN. The maximum value is 1500. For
PPPoE connections, there is always an 8-byte overhead, so the
maximum valid MTU value for PPPoE is 1492.
WAN MAC Address
Default – Use the default MAC address for the wireless WAN.
Customized - Select this option to use customized MAC addresses.
MAC - Specify a MAC address for the wireless WAN.

Discard current settings and return to previous page.
Save the current settings and exit the page.
Description
Click to show or hide the advanced settings (WAN MAC Address) for
the WAN interface.
Displays current WAN interface.
Displays the name of the profile.
Switch the toggle to enable or disable the function.
General Setup
Displays the physical type used by this interface.
At present, only Wireless 2.4GHz is available for WAN3 and Wireless
