II-1-5-6 WDS
Wireless Distribution System (WDS) is a protocol for linking access points (AP) wirelessly.
Vigor2136ax WDS only supports Repeater mode.

Repeater mode, which extends the coverage range of a WLAN.
Below shows Configuration>>Wireless LAN>>WDS web page:
Available settings are explained as follows:
Item
Reset
Refresh
Enabled
Mode
2.4GHz/5GHz WDS List
Description
Click to reset WPS with the default value.
Click to refresh current page.
Switch the toggle to enable/disable the WDS function.
Select the physical mode for this WDS setting.
HE(11ax)

VHT(11ac)

HTMIX(11n)

+Add – Click to create WDS list (up to 4).
Peer MAC Address – Enter the MAC address of the WDS peer.
