Connectors
Interface
Wireless LAN
WLAN On - Press the button and release it within 2 seconds. When the
ON/OFF/WPS
wireless function is ready, the green LED will be on.
WLAN Off - Press the button and release it within 2 seconds to turn off the
WLAN function. When the wireless function is not ready, the LED will be off.
WPS - When WPS function is enabled by web user interface, press this
button for more than 2 seconds to wait for client's device making network
connection through WPS.
Factory Reset
Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and keep for
more than 5 seconds. When you see the ACT LED begins to blink rapidly
than usual, release the button. Then the router will restart with the factory
default configuration.
2.5G WAN
Connector for remote networked devices (by Ethernet cable).
P1~P4
Connectors for local networked devices.
In which the transmission rate for P1(only) can reach 2.5G.
USB1~USB2
Connector for a USB device (USB Modem or printer).
ON/OFF
Power switch.
PWR
Connector for a power adapter.
Note
Remove the protective film from the router before use to ensure ventilation.
Explanation
4
