Draytek Vigor2136 Series User Manual page 109

Available settings are explained as follows:
Item
Interface
Area ID
Authentication
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
Description
Select a LAN / WAN interface to apply the settings configured for this
profile.
An AS will be divided into several areas. Each area must be assigned
with a dedicated number.
Please enter a number or IPv4 address as the area ID.
Select the authentication mechanism for this profile.
Disabled – No authentication mechanism will be used.
Plain-Text – Only password will be used for authentication.
Password –Enter characters as the password for MD5

authentication.
MD5 – Use MD5 authentication.
Password – Enter characters as the password for MD5

authentication.
Key ID – Enter a number (0~255). The ID will help Vigor router to

be identified in an autonomous system.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
99
