III-1-2-2 TR-069
Vigor device supports the TR-069 standard for remote management of customer-premises
equipment (CPE) through an Auto Configuration Server, such as VigorACS.
Available settings are explained as follows:
Item
TR-069
ACS Server On
IP/Domain
Username/Password
Event Code
CPE Client
Periodic Inform
Settings
Description
Switch the toggle to enable or disable the function.
ACS Server
Choose the interface for connecting the router to the Auto
Configuration Server.
Enter the IP/domain for connecting to the ACS.
Wizard - Click it to enter the IP address of VigorACS server, port
number and the handler.
Enter the credentials required to connect to the ACS server.
Test Connection
Use the drop down menu to specify an event to perform the test.
Test With Inform - Click it to send a message based on the event
code selection to test if such CPE is able to communicate with
VigorACS server.
More settings
This section specifies the settings of the CPE Client.
Protocol - Select Https if the connection is encrypted; otherwise select
Http.
Port - In the event of port conflicts, change the port number of the
CPE.
Username / Password - Enter the username and password that the
VigorACS will use to connect to the CPE.
Enable / Disable - Switch the toggle to enable or disable the function.
The default setting is Enable, which means the CPE Client will
periodically connect to the ACS Server to update its connection
