Session Limit Mode
QoS
Cancel
Apply
After finishing this web page configuration, please click Apply to save the settings.
II-1-10-2 Bandwidth Limit
Bandwidth Limit ensures LAN clients get their fair share of network bandwidth by placing
restrictions on upstream and downstream network speeds.
with different protocols.
Service Type Object – Click +Add to create a new object. Up to 12

objects can be created.
TCP/UDP – Select Transmission Control Protocol/User Datagram
Protocol.
Specify Source Port – Switch the toggle to enable the setting of

Source Port.
Source Port / Destination Port – Set the port range (1 to 65535).

TCP – Transmission Control Protocol. Setting method is the same as
TCP/UDP.
UDP – User Datagram Protocol. Setting method is the same as
TCP/UDP.
Traffic Shaping Policy
Disabled – Select to deactivate session limit function.
Per Source IP Limit – Apply the session limit to the traffic.
Max Sessions - The default maximum number of sessions

allowed per LAN client, unless overridden by specifying a different
number in the Limitation List.
Select the class level (Class 1, Class 2, Class 3 and others) of bandwidth
which will be applied to this profile.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
