Draytek Vigor2136 Series User Manual page 113

Name
Enabled
Schedule
Source / Destination
Source / Destination
IPv4 Address
Source / Destination
IPv4 Subnet Address
Source / Destination
IPv6 Address
Source / Destination
IPv6 Subnet Address
Source / Destination IP
Object
Source / Destination IP
Group
Protocol
Enter a name for identification.
Switch the toggle to enable/disable the traffic shaping policy profile.
Vigor router can perform the traffic shaping policy profile all the time
or on a certain date and time.
Always On - The function of traffic shaping policy profile is running all
the time.
Scheduled On - The function of traffic shaping policy profile is
activated based on the schedule profile.
Criteria
Specify the IP type.
Vigor router will restrict the sessions for the IPs by the default policy.
Any – If Any is selected, the limitation will applied to any IP.

IPv4 Address

IPv4 Subnet

IP Object

IP Group

It is available when Source / Destination is set as IPv4 Address.
+Add – Click to create a new entry.
IPv4 Address Start / End - Enter an IPv4 address as the starting point.
And, enter another IPv4 address as the ending point.
It is available when Source / Destination is set as IPv4 Subnet.
+Add – Click to create a new entry.
IPv4 Address – Enter an IPv4 address.
Subnet Mask – Specify the subnet mask for the IPv4 address.
It is available when Source / Destination is set as IPv6 Address.
+Add – Click to create a new entry.
IPv6 Address Start / End - Enter an IPv6 address as the starting point.
And, enter another IPv6 address as the ending point.
It is available when Source / Destination is set as IPv6 Subnet.
+Add – Click to create a new entry.
IPv6 Address – Enter an IPv6 address.
Prefix Length – Set the prefix length for the IPv6 address.
It is available when Source / Destination is set as IP Object.
+Add – Up to 12 objects can be specified here.
Select Object – Select the object(s) from the available object list on
the right side.
It is available when Source / Destination is set as IP Group.
+Add – Up to 12 groups can be specified here.
Select Group - Select the object(s) from the available group list on the
right side.
Only the traffic passing through the selected protocol will be limited.
Select one of the protocols from the drop-down menu.
Any – All traffic will be limited.
Service Type Object – Vigor system offers several service types set
103
