Available settings are explained as follows:
Item
Add Service
Enabled
Schedule
Source IP
Protocol & Port
Description
Select from list of predefined service, or manually configure triggering
and incoming protocols and ports.
Manually - If selected, self-define the service name.
Preset - If selected, various services will be offered for you to choose
as the service name.
Switch the toggle to enable or disable the function of port triggering.
Vigor router can perform the port triggering all the time or on a
certain date and time.
Always On - The function of port triggering is running all the time.
Scheduled On - The function of port triggering is activated based on
the schedule profile.
Triggering Source
Any - Any source IP will be forwarded to a LAN.
IP Address - Set a range of IP addresses forwarded to a LAN.
IP Address – Enter the IP address and the subnet mask.

IP Object – Click +Add to specify the IP object profile (up to 12
profiles).
IP Group - Click +Add to specify the IP group profile (up to 12 profiles).
+Add - Click to set port numbers (start and end) for the specified
protocol (TCP, UDP or TCP/UDP) for the outgoing data (that this rule
monitors).
Triggering Protocol - The protocol(s) of the outgoing traffic.
 TCP - open port(s) to TCP traffic.
UDP - open port(s) to UDP traffic.

TCP/UDP - open port(s) to both TCP and UDP traffic.

Select the protocol (TCP, UDP or TCP/UDP) for the outgoing data of
such triggering profile.
