Enable Mesh
Mesh Protocol
Group Name
Wireless Download
Band
Auto Wireless Uplinks
Optimization
Log Level
Enable AP
Management
Cancel
Apply
system.
Ready – If the password is set or changed manually, after finishing the
configuration, the word "Ready" will be shown instead.
Mesh Setup
Switch the toggle to enable or disable the mesh function.
Select the mesh protocol to manage the mesh network.
Vigor Mesh – A protocol developed by DrayTek.
Displays the name of the current mesh group. Change the name if
required.
It is available only when Advanced Mode is set to On.
Select a wireless band (Auto, 2.4GHz or 5GHz) for connecting with a
downlink mesh root or a downlink mesh node.
It is available only when Advanced Mode is set to On.
It is enabled in default. To perform the auto reselect, make sure the
process for CFG Sync and CFG Check for mesh nodes (members) are
successful. If enabled, after changing the environment of mesh
network (e.g., offline, disconnection), the root device will perform auto
reselect to reconstruct the mesh network.
It is available only when Advanced Mode is set to On.
Choose Basic or Detailed. Related information will be shown on
Syslog.
AP Management Setup
Switch the toggle to enable/disable the AP Management.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
