3-10 Option Installation

Checking the Memory in the System

Use the following procedure to:
n
check the memory installed in the system
n
to determine the SIMM configuration you need to increase the memory
n
to identify the correct sockets for SIMM installation.
1. Locate the four SIMM sockets on the system board (see Figure 3-2).
If any cables block access to the SIMM sockets, label and disconnect them.
Use Table 3-1 to determine the SIMM configuration you need to upgrade
2.
memory and to identify the sockets for SIMM installation.
Table 3-1 Recommended Memory Upgrade Path
Total
Memory Bank 0
8 MB 4 MB
16 MB 4 MB
16 MB* Empty
32 MB 8 MB
32 MB 16 MB
64 MB 16 MB
64 MB 32 MB
128 MB 32 MB
* Standard configuration.
Bank 0 Bank 1
4 MB Empty
4 MB 4 MB
Empty 8 MB
8 MB 8 MB
16 MB Empty
16 MB 16 MB
32 MB Empty
32 MB 32 MB
Bank 1
Empty
4 MB
8 MB
8 MB
Empty
16 MB
Empty
32 MB
