C
ONFIGURING THE
CLI – This example creates trunk 2 with ports 1 and 2. Just connect these
ports to two static trunk ports on another switch to form a trunk.
Console(config)#interface port-channel 1
Console(config-if)#exit
Console(config)#interface ethernet 1/5
Console(config-if)#channel-group 1
Console(config-if)#exit
Console(config)#interface ethernet 1/6
Console(config-if)#channel-group 1
Console(config-if)#end
Console#show interfaces status port-channel 1
Information of Trunk 1
Basic information:
Port type:
Mac address:
Configuration:
Name:
Port admin:
Speed-duplex:
Capabilities:
Flow control:
Port security:
Max MAC count:
Current status:
Created by:
Link status:
Operation speed-duplex: 100full
Flow control type:
Member Ports: Eth1/5, Eth1/6,
Console#

Enabling LACP on Selected Ports

Command Usage
• To avoid creating a loop in the network,
be sure you enable LACP before
connecting the ports, and also
disconnect the ports before disabling
LACP.
• If the target switch has also enabled
LACP on the connected ports, the trunk
will be activated automatically.
• A trunk formed with another switch
using LACP will automatically be
assigned the next available trunk ID.
3-112
S
WITCH
100TX
00-30-F1-B3-16-C5
Up
Auto
10half, 10full, 100half, 100full
Enabled
Disabled
0
User
Down
None
dynamically
enabled
active
links
configured
members
4-174
4-174
4-194
4-183
backup
link
