CLI – This example creates trunk 2 with ports 1 and 2. Just connect these
ports to two static trunk ports on another switch to form a trunk.
Console(config)#interface port-channel 2
Console(config-if)#exit
Console(config)#interface ethernet 1/1
Console(config-if)#channel-group 1
Console(config-if)#exit
Console(config)#interface ethernet 1/2
Console(config-if)#channel-group 1
Console(config-if)#end
Console#show interfaces status port-channel 1
Information of Trunk 1
Basic information:
Port type: 1000T
Mac address: 00-00-E8-AA-AA-01
Configuration:
Name:
Port admin: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full, 1000full,
Flow control: Disabled
Port security: Disabled
Max MAC count: 0
Port security action: None
Current status:
Created by: User
Link status: Down
Operation speed-duplex: 1000full
Flow control type: None
Member Ports: Eth1/1, Eth1/2,
Console#

Enabling LACP on Selected Ports

Command Usage
• To avoid creating a loop in the
network, be sure you enable LACP
before connecting the ports, and also
disconnect the ports before disabling
LACP.
• If the target switch has also enabled
LACP on the connected ports, the
trunk will be activated automatically.
P C
ORT ONFIGURATION
dynamically
enabled
active
links
configured
members
4-132
4-132
4-151
4-140
backup
link
3-85
