Configuring 802.1x Global Settings

The 802.1x protocol must be enabled globally for the switch system before
port settings are active.
Web – Click Security, 802.1x, Configuration. Check the Enabled box and
click Apply to enable 802.1x globally for the switch.
CLI – This example enables 802.1x globally for the switch and shows the
current setting.
Console(config)#dot1x system-auth-control
Console(config)#
Console#show dot1x
Global 802.1X Parameters
system-auth-control: enable
802.1X Port Summary
Port Name
Authorized
1/1
1/2
.
.
.
802.1X Port Details
802.1X is disabled on port 1/1
802.1X is disabled on port 26
.
.
.
Console#
3-80
S
WITCH

Figure 3-35 802.1x System Authentication Control

Status
disabled
disabled
Operation Mode
Single-Host
Single-Host
Mode
ForceAuthorized
ForceAuthorized
4-113
4-119
n/a
n/a
