SMC Networks 6824MPE INT Management Manual page 247

Web – Click Priority, ACL Marker. Select a port and an ACL rule. To
specify a ToS priority, mark the Precedence/DSCP check box, select
Precedence or DSCP from the scroll-down box, and enter a priority. To
specify an 802.1p priority, mark the 802.1p Priority check box, and enter a
priority. Then click Add.
CLI – This example changes the DSCP priority for packets matching an
IP ACL rule, and the 802.1p priority for packets matching a MAC ACL
rule.
Console(config)#interface ethernet 1/1
Console(config-if)#match access-list ip bill set dscp 0
Console(config-if)#match access-list mac mike set priority 0 4-154
Console(config-if)#end
Console#show marking
Interface ethernet 1/1
match access-list IP bill set DSCP 0
match access-list MAC a set priority 0
Console#
C
LASS OF
Figure 3-89 ACL Marker
S C
ERVICE ONFIGURATION
4-174
4-141
4-142
3-197
