Command Mode
Global Configuration
Example
The following example shows how to set the interface configuration mode to
VLAN 1, and then assign an IP address to the VLAN.
Console(config)#interface vlan 1
Console(config-if)#ip address 192.168.1.254 255.255.255.0
Console(config-if)#
Related Commands
shutdown (4-180)

switchport mode

Use this command to configure the VLAN membership mode for a port.
Use the no form to restore the default.
Syntax
switchport mode {trunk | hybrid}
no switchport mode
• trunk - Specifies a port as an end-point for a VLAN trunk. A trunk is
a direct link between two switches, so the port transmits tagged
frames that identify the source VLAN. Note that frames belonging to
the port's default VLAN i.e., associated with the PVID) are also
transmitted as tagged frames.
• hybrid - Specifies a hybrid VLAN interface. The port may transmit
tagged or untagged frames.
Default Setting
All ports are in hybrid mode with the PVID set to VLAN 1.
Command Mode
Interface Configuration (Ethernet, Port Channel)
VLAN C
OMMANDS
4-231
