Web – Click Priority, Copy Settings. Select the source priority settings to
be copied, enter the source port or trunk number and choose the
destination interface/s to copy to, then select Copy Settings.
Figure 3-87 Mapping Priority Settings to Ports/Trunks
CLI – The following example shows how to map HTTP traffic to CoS
value 0 on port 5, maps IP precedence to CoS 0 to port 6, and enables
mapping IP DSCP globally.
Console#con
Console(config)#interface ethernet 1/5
Console(config-if)#map ip port 80 cos 0
Console(config)#interface ethernet 1/6
Console(config-if)#map ip precedence 1 cos 0
Console(config-if)#exit
Console(config)#map ip dscp
Console(config)#
C S
LASS OF ERVICE
C
ONFIGURATION
4-252
4-254
4-255
3-193
