Appendix A

Host Interfaces

1. Serial RS-232 or RS-422 at 600, 1200, 2400, 4800, 9600, 19200,
38400, 57600, or 115200 baud.
2. Parallel (Centronics compatible) or IEEE 1284 bi-directional.
The RS-232 and RS-422 host interfaces shall have the following
characteristics:
Character Set:
Word Length:
Handshaking:
Input Buffer:

Power

Power Source:
Grounding:
203 dpi
10 ips
Energy Star
(Power Saver Mode) 24 Watts
Standby 50 Watts
25% Print Density 142 Watts
50% Print Density 234 Watts
342
Table 26. Host Interface Characteristics
ANSI
Selectable 7-bit or 8-bit data format
XON/XOFF (in receive mode only) and
CTS/DTR
Selectable from 1k through 16 kbytes. XOFF is
transmitted and DTR goes low when buffer is
equal to or less than 25% of full. XON is
transmitted and DTR goes high when buffer is
25% above empty. Characters are transmitted
with no parity from the printer
Table 27. Power Source and Grounding
115 or 230 VAC 50/60Hz switching power
supply.
Unit must be connected to a properly
grounded receptacle.
Table 28. Power Consumption
4 inch printers 6 inch printers
300 dpi 203 dpi
8 ips 10 ips
24 Watts 24 Watts
50 Watts 50 Watts
143 Watts 205 Watts
235 Watts 360 Watts
®
ASCII character set
8 inch printers
300 dpi 203 dpi
8 ips 8 ips
24 Watts 24 Watts
50 Watts 50 Watts
175 Watts 213 Watts
300 Watts 375 Watts
300 dpi
6 ips
24 Watts
50 Watts
212 Watts
373 Watts
