7. Thread the media under the media damper and then between the platen

(rubber drive roller) and the printhead.

You can also refer to the arrows on the printer frame or to the label inside

the media cover for media loading instructions.

Platen (Rubber

Drive Roller)

Loading Roll Media

Media Loading

Instruction Label

Media Damper
