Loading Ribbon

Skip this section for 4 inch DT models or when using direct

thermal printing.

1. Install the empty ribbon supply core onto the take-up spindle.

2. Slide the ribbon roll onto the ribbon supply spindle until it stops against

the spindle flange.

3. Open the pivoting deck by rotating the deck lock lever fully clockwise until

the deck swings upward.

Loading Ribbon

Empty Supply

Ribbon Supply
