Chapter 3
SER MATRIX SETUP
SER MATRIX SETUP
(cont. from prev. page)
Define CR code
(page 210)
Auto LF
(page 198)
Define LF code
(page 211)
Control Code 06
(page 209)
Bold
(page 200)
Overstrike
(page 229)
Printer Select
(page 232)
Alt. Set 80-9F
(page 197)
ESC d command
(page 214)
Text Position
(page 241)
Host Command
(page 219)
Reset Cmd CFG Ld
(page 234)
(2)(3)
Form Length
(page 216)
(2)(3)
Form Length
(page 216)
(2)
Form Length
(page 216)
(3)(5)
Form Width
(page 217)
(3)(5)
Form Width
(page 217)
(5)
Form Width
(page 217)
190
CR = CR* CR = CR + LF
Enable* Disable
LF = LF* LF = CR + LF
8.0 LPI* 10.3 LPI
Disable* Enable
Enable* Disable
Disable* Enable
(1)
Control Code* Printable
Even dot plot* Double high
Bottom of Line* Top of Line
Enable* Ignore All
Disable* Power up config
(4)
4 or 6 inches*
(4)
101.6 or 152.4 mm*
(4)
24 or 36 lines*
(4)
04.1, 06.6, or 08.5 inches*
(4)
104.1, 168.0, or 215.9 mm*
(4)
41, 66, or 85 characters*
Notes:
* = Factory Default
1
6.0 LPI
When the CTHI option is installed,
the factory default is Printable.
2
All three Form Length submenus
work in conjunction. When you
change the default in one
submenu, the default values in the
other two submenus change
automatically.
3
These menus do not display when
the CT, TN5250, or TN3270
emulation is selected.
4
The factory default value depends
on the width of the printer model.
5
All three Form Width submenus
work in conjunction. When you
change the default in one
submenu, the default values in the
other two submenus change
automatically.
Ignore CPI Ignore LPI
Current config
00.0 to 24.0 inches
00.0 to 609.6 mm
0 to 144 lines
00.0 to 13.6 inches
00.0 to 345.4 mm
0 to 272 characters
Factory config
