Zebra Xilll Series
Network ID (000* - 999) used for RS-422/
RS-485 Network only.
Communications -
Normal Mode* - Prints label image.
Diagnostics - All data sent from host printed
in ASCII hex chars.
Control Prefix - (00 – FF) Hex 7E*
Format Prefix - (00-FF) Hex 5E*
Delimiter Char. - (00-FF) Hex 2C*
ZPL Mode - ZPLII*, ZPL
Media Power Up - Media action when the
printer is powered up.
Feed* - Feeds a label to1st web.
Calibration - Recalibrates media when
printer is powered up.
Length - Determines length of label.
No Motion - Media does not move.
Head Close - Media action after the print-
head is closed.
Feed* - Feeds a label to1st web.
Calibration - Recalibrates media.
Length - Determines length of label.
No Motion - Media does not move.
Backfeed - (Default*, after, before, 10 to
90%, off). Establishes when & how much
label backfeed occurs after a label is cut or
peeled-off.
Table 32: PPI1 Menu (continued)
N/A
NOTE: Ptr Defaults to Normal Mode Comm. Hex Dump
(same as Zebra Diagnostic Mode) can be Enabled in
DIAGNOSTIC Menu.
IGP/PPI1 SETUP Menu,
Command Prefix - (1-255) 126*.
= Hex 7E*
Label Prefix - (1 to 255) 94*. = Hex 5E*
Delimiter - (1 to 255) 44*. = Hex 2C*
ZPL Compatibility - ZPL-II*, ZPL-1
CALIBRATE CTRL Menu,
NOTE: T5000e auto feeds a blank label to 1st web (gap)
when first print job is sent.
Pwr Up Auto-Cal - (Disable*, Enable)
Disable* - No recalibrate at power-up.
Enable - Recalibrates media when printer is powered up.
MEDIA CONTROL Menu,
Set Label Length -
Manual* - Label Length set in menu.
Automatic - Auto Calibrate Sensed Distance value used
to set Label Length.
N/A
N/A (No menu option available).
NOTE: After printhead is closed, T5000e auto feeds a
blank label to first web (gap) when first print job is sent.
N/A
N/A
N/A
N/A Distance back to TOF position of label under
printhead is auto controlled by T5000e regardless of
Paper Feed Shift value when using; Cut, Tear-Off, Tear-
Off Strip & Peel-Off Media Handling modes.
T5000e with PPI1 Emulation
