Calibrate Ctrl - Printronix SL5000E series User Manual

Chapter 3

CALIBRATE CTRL

CALIBRATE CTRL
CALIBRATE CTRL
(1)
Gap/Mark Sensor
Auto Calibrate
Media Profile
Sensed Distance
0.00 inches
Gap/Mark Thresh
Paper Out Thresh
(1)
Paper Out Sensor
Manual Calibrate
Pwr Up Auto-Cal
Online Auto-Cal
Gap Windowing
Gap Length 0.12 inches*
Cal in Peel Mode
Min Calib Delta
Use Label Length
134
Disable* Mark
Run Calibrate
Print Profile
(2)
171* 000-255
136* 000-255
Reflective* Transmissive
Run Calibrate
Disable* Enable
Disable* Enable
Disable* Enable
0.05 - 1.00 inches
Disable* Enable
(3)
012* 012 - 050
Enable* Disable
Gap Advanced Gap
Notes:
* = Factory Default
Italicized items are available only when you enable
Admin User (in the PRINTER CONTROL menu).
1
Gap/Mark Sensor and Paper Out Sensor work in
conjunction, as shown below:
Table 6
When you select an
Paper Out Sensor
option in Gap/Mark
defaults to...
Sensor...
Disable Reflective
Mark Reflective
Gap Reflective
Advanced Gap Transmissive
Advanced Notch Transmissive
If you change the Gap/Mark Sensor or Paper Out
Sensor, you must recalibrate the media.
2
When Admin User is enabled (in the PRINTER
CONTROL menu), you can change the unit value to
millimeters: Under the Units submenu (in the MEDIA
CONTROL menu), enable the "In Millimeters"
option.
3
When Gap/Mark Sensor = Disable, Gap, or Mark,
the default is 12. When Gap/Mark Sensor =
Advanced Gap or Advanced Notch, the default is 20.
Advanced Notch
