TEC B-470/870 Series
PARAMETER SET MODE,
Feed Adjust - (-50.0 to +50.0 MM) +0.0 MM*
- Feed length, fine adjustment. Adjusts
vertical print position on label. (- ) value
moves the image down from the leading edge
of the label. (+ ) value moves the image up
toward the leading edge of the label.
PARAMETER SET MODE,
Cut Adjust - (-50.0 to +50.0 MM)+0.0 MM -
Cut or tear off strip position, fine adjustment.
(- ) value sets leading edge of label behind
the tear bar. (+) value sets the leading edge of
the label past the tear bar.
PARAMETER SET MODE,
Back Feed - (-9.5 to +9.5 MM)
+0.0 MM - Adjusts vertical print position on
label. (+) value moves the image down from
the leading edge of the label. (-) value moves
the image up toward the leading edge of the
label.
PARAMETER SET MODE,
X Adjust - (-99.0 to +99.0 MM)
+0.0 MM - X axis (horizontal) print position,
fine adjustment. (+) value shifts image left. (-)
value shifts image right.
PARAMETER SET MODE,
Tone Adjust <T> - (-10 to +10) +0*.
Darkness of image on label for Thermal
Transfer printing (use of ribbon).
PARAMETER SET MODE,
Toner Adjust <D> - (-10 to +10) +0*.
Darkness of image on label for Direct
Thermal printing (no ribbon).
PARAMETER SET MODE,
Font Code - (PC-850* or PC-8)
PARAMETER SET MODE,
Zero Font - (0* or Ø) Selects 0 or slashed Ø.
PARAMETER SET MODE,
Code - (Auto*, ESC, LF, NUL or { | } )
Selects the command code.
Table 33: PPI2 Menu
T5000e with PPI2 Emulation
QUICK SETUP Menu,
Ver Image Shift - (-1 to+12.8") 0.0*". Adjusts vertical
print position on label.
(- ) value moves the image up toward the leading edge of
the label. (+ ) value moves the image down from the
leading edge of the label.
QUICK SETUP Menu,
Paper Feed Shift - (-0.50 to+12.8) 0.00 Inch* - Adjusts
Tear Off, Tear-Off Strip, Peel-Off & Cut position in Inches
or MM. (-) value sets leading edge of label behind tear
bar. (+) value sets the leading edge of the label past the
tear bar.
QUICK SETUP Menu,
Ver Image Shift - (-1 to+12.8") 0.0*". Adjusts vertical
print position on label.
(+) value moves the image down from the leading edge of
the label. (-) value moves the image up toward the
leading edge of the label.
QUICK SETUP Menu,
Hor Image Shift - (-1.0 to +1.0) 0.0"*.
Adjusts image horizontally from left edge of label in
inches. (+) value shifts image left. (-) value shifts image
right.
QUICK SETUP Menu,
Print Intensity - (-15 to +15) -3*
Print Mode - (Transfer, Direct)
QUICK SETUP Menu,
Print Intensity - (-15 to +15) 0*
Print Mode - (Transfer, Direct)
IGP/PPI2 SETUP Menu,
Character Set - (PC-850* or PC-8)
IGP/PPI2 SETUP Menu,
Slash Zero - (0* or Ø).
IGP/PPI2 SETUP Menu,
SFCC Select - (Auto Select*, ESC, LF, NUL, User
Defined or { | })
