Appendix F
TEC B-470/870 Series
PARAMETER SET MODE,
Ribbon - (Trans. or Non-Trans*) -
Non-Transmissive - With ribbon
Transmissive - Ribbon out
Auto Ribbon Save Function - (Without*,
With) – (Opt) Dip SW 1 (1)
Language - Sets the display language.
English*, Spanish, French, German, Dutch,
Japanese. Dip SW 1 (2-4)
Rewinder Use- (Without*, With)
Dip SW 1 (6)
Baud Rate - (9600*, 2400 - 19200)
Dip SW 2 (1-2)
Stop Bits – (1 bit* or 2 bits)
Dip SW 2 (3)
Word Length – (7-bits* or 8-bits)
Dip SW 2 (4)
Parity Check - (With* or Without)
Dip SW 2 (5)
Parity - (Even* or Odd)
Dip SW 2 (6)
Data Protocol - XON/XOFF*, Ready Busy
(DTR), XON/XOFF +Ready Busy(DTR).
DIP SW 2 ( 7-8)
N/A
N/A
N/A
372
Table 33: PPI2 Menu (continued)
T5000e with PPI2 Emulation
QUICK SETUP Menu,
Print Mode - (Transfer* or Direct)
N/A
PRINTER CONTROL Menu,
Display Language - English*, Spanish, French,
German, Italian, Portuguese.
Factory installed Option - No menu selection required.
SERIAL PORT,
Baud Rate - (9600*, 600 - 115200)
SERIAL PORT,
Stop Bits - 1* or 2
SERIAL PORT,
Word Length 7 or 8*
SERIAL PORT,
Parity - (None*, Even, Odd)
SERIAL PORT,
Parity - (None*, Even, Odd)
SERIAL PORT,
Data Protocol -
(XON/XOFF*, ETX/ACK, ACK/NAK, Series 1 Char,
Series 2 Char or DTR)
IGP/PPI2 SETUP Menu,
Active - (Yes*, No)
Yes - All data is parsed by the PPI2 emulation. Non-PPI2
data is absorbed.
No – All data is passed to the LP+ emulation.
IGP/PPI2 SETUP Menu,
Image Scale - (Disable*, Enable)
Enable - Images are scaled from TEC printer resolution
(306 dpi) to PPI2 resolution (300 dpi).
Disable - No scaling, resulting in 2% larger images on
PPI2 printers vs TEC printers.
IGP/PPI2 SETUP Menu,
EURO Symbol - (0x0 - 0xFF) 0XB0*
Allows configuration position of _ symbol in the code
pages.
